Name: SS304L 168mm Johnson VEE-WIRE Water Well Screen Pipe
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: 6-5/8 "
Price: 200.00 USD
Availability: InStock

Maison > PRODUITS > filtre pour puits de l'eau >

SS304L 168mm Johnson VEE-WIRE Water Well Screen Pipe

SS304L water well screen pipe

168mm Johnson VEE-WIRE screen

stainless steel well screen pipe

Lieu d'origine:

Hengshui, Hebei, Chine

Nom de marque:

Heng Yuan

Certification:

ISO9000

Numéro de modèle:

6-5/8 "

Contactez-nous

Demandez une citation

Détails de produit

name:

Johnson VEE-WIRE Tuyaux de détection de puits d'eau

Matériel:

Acier inoxydable 304L

Diamètre:

168mm

Longueur:

5850mm

Taille de la fente:

0.5 mm

Fil d'enveloppe:

3×4.6mm

Rameau de support:

ø6.8mm

No. de tige:

32NOS

Connexion de fin:

Mâle/femelle fileté

Le poids:

90 kg/pièce

Paquet:

Films en plastique

Utiliser:

Dans des puits d'eau pour le contrôle de sable

Produits connexes

Vidéo

10-3/4 Inch SS304 Water Well Screen with #20 Slot

Obtenez le meilleur prix

Vidéo

219mm Stainless Steel Johnson Water Well Screen 1.0mm Slot

Obtenez le meilleur prix

Vidéo

Type écran de blessure de tuyau d'enveloppe de Johnson pour le filtre de puits de pétrole de puits d'eau

Obtenez le meilleur prix

Vidéo

Élément de filtre enveloppé de fil de l'écran V de fil de Johnson d'acier inoxydable

Obtenez le meilleur prix

Contactez-nous

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Contact maintenant

Description de produit

SS304L 6-5/8" Johnson VEE-WIRE Water Well Screen Pipe

Product Specifications

Attribute	Value
Name	Johnson VEE-WIRE Water Well Screen Pipe
Material	Stainless Steel 304L
Diameter	168mm
Length	5850mm
Slot size	0.5mm
Wrap wire	3×4.6mm
Support rod	ø6.8mm
NO. of rod	32NOS
End connection	Male/female threaded
Weight	90KG/piece
Package	Plastic film
Use	In water wells for sand control

Product Description

Our Johnson VEE-WIRE Water Well Screen Pipe, also known as wedge wire screens or continuous slot water well screens, represents the pinnacle of quality in sand control solutions. Manufactured in our state-of-the-art facility, these screens combine precision engineering with durable non-magnetic stainless steel construction.

Key Features

Available in pipe-base configuration for deep wells and rod-base for shallow wells
Optimized manufacturing processes ensure consistent quality and performance
Streamlined production for reliable on-time delivery
Precision slot sizes from 0.1-100mm available
Custom configurations to meet specific application requirements

Standard Specifications

Name	Johnson VEE-WIRE Water Well Screen Pipe, Continuous Slot Water Well Screen, Oil Well Sand Screen, Wedge Wire Screen
Material	Stainless steel 202, 304, 304L, 316L, Non-magnetic Stainless steel, Low carbon galvanized
Diameter	3", 4", 6", 8", 10", 12", 14", 16", 18" (custom sizes available)
Slot Size	0.1-100mm (standard sizes: 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)
Length	100-6000mm (standard lengths: 2.9m/3m and 5.8m/6m for container shipping)
Wrap Wire	2×3.5mm, 2.2×3.5mm, 3×4.6mm, 3×5mm, 3×6mm, 3×6.5mm, 3.2×6mm, 4×7mm
Support Rod	ø3.0-ø6.0mm round wire or Vee-shaped wire options
End Connections	Welded rings, Plain beveled ends, Male/female threaded, Flange

Industry Applications

Water Well Systems
Food & Beverage Processing
Pharmaceutical & Biological
Refining & Petrochemical
Water Treatment & Separation
Mineral & Aggregate Processing
Pulp & Paper Manufacturing
Environmental Protection
Architecture & Construction
